전원 OFF: 배터리잭을 분리하여 전원 OFF !!!
| Length: | 30.67 inches (779 mm) |
|---|---|
| Front Track: | 21.3 inches (540 mm) |
| Rear Track: | 21.3 inches (540 mm) |
| Ground Clearance: | 4.2 inches (107 mm) |
| Weight: | 22.20 pounds (9.5 kg) 25.06 pounds (11.39 kg) with two 4s 6700 mAh LiPo batteries |
| Height (ride): | 13.99 inches (355 mm) |
| Wheelbase: | 18.92 inches (480 mm) |
| Shock Length: | 7.4 inches (187 mm) |
| Tires (pre-glued): | Belted Sledgehammer® 8.4″ x 4.0″ (203 mm) |
| Wheels: | 4.3″ x 5.7″ (110x145 mm) |
| Wheel Hex Size: | 24 mm splined hex |
| Speed Control: | Velineon® VXL-8s™ |
| Motor (electric): | Velineon 1200XL |
| Transmission: | Single-speed |
| Overall Drive Ratio: | 8.11 (stock, out-of-box) |
|---|---|
| Differential Type: | Sealed, hardened steel bevel, limited slip |
| Gear Pitch: | Module 1.0 |
| Chassis Structure/Material: | Composite nylon tub |
| Brake Type: | Electronic |
| Drive System: | Shaft-driven 4WD |
| Steering: | Aluminum bellcrank |
| Radio System: | TQi™ 2.4 GHz transmitter with factory-installed wireless module |
| Servo: | Torque: 450 oz-in speed: 0.17 sec/ 60 degrees (6.0 volts) |
| Top Speed: | 50+ mph with two 4s LiPo batteries and optional gearing (sold separately) |
| Skill Level: | 6 |
| Battery Tray: | 197 mm x 52 mm x 44 mm |
| Required Batteries: | 4 “AA” (transmitter) and 3-cell LiPo battery (x2) or 4-cell LiPo battery (x2) |
-Motor spec
| Type: | 1275 kV sensorless brushless |
|---|---|
| Weight: | 23.44 ounces (665 g) |
| Length: | 4.32 inches (110 mm) |
| Diameter: | 1.88 inches (48 mm) |
| Connector Type: | Traxxas 6.5 mm bullet connectors |
-ESC Spec
| Input Voltage: | 8s LiPo (max 33.6 volts) |
|---|---|
| Case Size: | 2.23″ (58 mm) / 2.83″ (72 mm) / 1.81″ (46 mm) |
| Weight: | 7.60 ounces (215.5 g) |
| BEC Voltage: | 6.0 volts |
| BEC Current Continuous: | 10 amps |
| BEC Current Peak: | 20 amps |
| Motor Connectors: | Traxxas 6.5 mm bullet connectors |
| Battery Connectors: | Traxxas High-Current Connectors |
| Power Wire: | 10-gauge Maxx Cable |
| Ports: | RX Input, auxiliary fan, accessory port |
