| Length: | | 20.57 inches (523 mm) |
| Front Track: | | 9.78 inches (249 mm) |
| Rear Track: | | 9.78 inches (249 mm) |
| Ground Clearance: | | 3.14 inches (80 mm) |
| Weight: | | 102.72 ounces (2.91 kg) |
| Height: | | 10.47 inches (266 mm) |
| Wheelbase: | | 12.28 inches (312 mm) |
| Front Shock Length: | | 3.54 inches (90 mm) |
| Rear Shock Length: | | 3.54 inches (90 mm) |
| Approach Angle: | | 63.82° |
| Departure Angle: | | 43.22° |
| Breakover Angle: | | 59° |
| Front Wheels: | | 1.9 x 1.02 inches (49 x 26 mm) |
| Rear Wheels: | | 1.9 x 1.02 inches (49 x 26 mm) |
| Front Tires: | | 4.64 x 1.89 inches (118 x 48 mm) |
| Rear Tires: | | 4.64 x 1.89 inches (118 x 48 mm) |
| Wheel Hex: | | 12 mm |
| Speed Control: | | XL-5™ HV |
| Motor (electric): | | Titan® 21T reverse rotation |
| Differential Type: | | 4 gear, remote locking |
| Transmission: | | 2-speed Hi-Lo, remote shifting |
| Gear Pitch: | | 32 |
Chassis
Structure/Material: | | Steel ladder frame with Nylon composite cross members |
| Brake Type: | | Electronic “Hill Hold” |
| Drive System: | | Shaft-driven 4WD |
| Steering: | | Chassis mounted 2075X metal gear servo |
| Radio System: | | TQi™ 2.4 GHz 4-channel transmitter with 6533 receiver |
| Skill Level: | | 2 |
| Battery Tray: | | 158.75 mm L x 47 mm W x 23/26 mm H |
