- 충전시 40와트 이상의 USB파워 연결이 필요합니다. (충전기 허용 입력 5~20V,3A)
| |
|---|
| | |
|---|
| Length: | 14.8 inches (376 mm) |
|---|
| Front Track: | 11 inches (279 mm) |
|---|
| Rear Track: | 11 inches (279 mm) |
|---|
| Ground Clearance: | 1.06 inches (27 mm) |
|---|
| Weight: | 3.99 pounds (1.81 kg) |
|---|
| Height: | 5 inches (127 mm) |
|---|
| Wheelbase: | 8.66 inches (220 mm) |
|---|
| Shock Length: | 3.45 inches (88 mm) |
|---|
| Tire Diameter: | 3.7 inches (94 mm) |
|---|
| Wheel Diameter: | 2.1″ (53 mm) outer, 2.6″ (66 mm) inner |
|---|
| Speed Control: | VXL-3s brushless ESC |
|---|
| Motor (electric): | Velineon 3500 (3500 Kv) |
|---|
| Transmission: | Direct-drive with center differential |
|---|
Overall Drive Ratio: 7.36:1 |
|
|---|
| |
|---|
| Differential Type: | Planetary, steel gear |
|---|
| Gear Pitch: | 32 |
|---|
| Chassis Structure/Material: | Composite modular tub |
|---|
| Brake Type: | Electronic |
|---|
| Drive System: | Shaft-driven 4WD |
|---|
| Steering: | Double-shear bellcrank |
|---|
| Wheels & Tires: | Black dual-profile XRT wheels with pre-glued 4″ Gravix tires |
|---|
| Radio System: | TQi 2.4 GHz high output(2-channel) w/ TSM |
|---|
| Servo: | Waterproof high-torque, metal-gear 2075X |
|---|
| Top Speed: | 55+ mph |
|---|
| Skill Level: | 1 |
|---|
| Battery Tray: | 113 mm L x 41 mm W x 22 mm H |
|---|
| Required Batteries: | 4 “AA” (transmitter) |
|---|
- Motor Spec| Type: | Velineon 3500 Kv sensorless brushless |
|---|
| Weight: | 9.24 ounces (262 g) |
|---|
| Length: | 3.03 inches (77 mm) |
|---|
| Diameter: | 1.41 inches (36 mm) |
|---|
| Connector Type: | 3.5 mm bullet |
|---|
- ESC Spec| Input Voltage (cells): | 7.4 – 11.1 volts, 2s–3s LiPo |
|---|
| Case Size: | 2.19″ (56 mm) x 1.54″ (39 mm) x 1.3″ (33 mm) |
|---|
| Weight: | 3.84 ounces (109 g) |
|---|
| BEC Voltage: | 6.0 volts |
|---|
| Reverse Delay: | Yes, with lockout |
|---|
| Thermal Protection: | Two-stage thermal shutdown |
|---|
| Ports: | Auxiliary fan |
|---|
Key Features- 1/10 Velineon® VXL-3s™ Brushless Power System
- TQi™ 2.4 GHz Radio System with Traxxas Stability Management® (TSM)
- 1/10 Driveline with Center Differential in a Compact Chassis
- Full-Size 2075X Metal-Gear Steering Servo
- 3.7″ Gravix® Tires with Foam Inserts
| |
|---|
|
