| Model Name: | Slash Late Model BL-2s |
|---|---|
| Model Type: | Short Course Trucks |
| Model Speed: | 35+ |
| Model Skill Level: | 1 |
| Scale: | 1/10 |
| Weight: | 5.62 pounds (2.55 kg) |
| Length: | 25.8 inches (656 mm) |
| Width: | 12.3 inches (313 mm) |
| Front Track: | 12.3 inches (313 mm) |
| Rear Track: | 12.3 inches (313 mm) |
| Height: | 8.52 inches (216 mm) |
| Wheelbase: | 12.3 inches (333 mm) |
|---|---|
| Center Ground Clearance: | 1.38 inches (35 mm) |
| Drivetrain: | 2WD |
| Transmission: | Magnum 272R™ |
| Differential Type: | Sealed, hardened steel bevel, limited slip |
| Gear Ratio (Internal): | 9.10:1 |
| Gear Pitch: | 48 pitch |
| Servo(s): | 2075 digital high-torque waterproof |
| Radio System: | TQ™ 2.4 GHz 2-channel radio |
| Battery Compartment Specs: | 165 mm X 50 mm X 23 mm, 25 mm |
- MOTOR SPECS
| Motor Name: | BL-2s 3300 Kv |
|---|---|
| Motor Type: | Sensorless brushless |
| Motor Weight: | 7.51 ounces (213 g) |
| Motor Length: | 3.15 inches (80 mm) |
| Motor Diameter: | 1.42 inches (36 mm) |
| Motor Shaft Size: | 3 mm |
| Motor Connector Type: | Traxxas Quick Connect Motor Plug |
- ESC SPECS
| ESC Name: | BL-2s Electronic Speed Control |
|---|---|
| ESC Type: | Brushless |
| ESC Case Size: | 1.53″ (39 mm) x 2.31″ (59 mm) x 1.21″ (31 mm) |
| ESC Weight: | 3.07 ounces (87 g) |
| Motor Connectors: | Traxxas Quick Connect Motor Plug |
| Battery Connectors: | Traxxas High-Current Connector |
