Name: Stampede 4X4 Brushless

Type: Monster Truck

Speed: 35+ mph with 2s LiPo battery, 50+ mph with 3s

Skill Level: 1

Scale: 1/10

Weight: 5.98 pounds (2.7 kg)

Length: 17.87 inches (454 mm)

Width: 13.10 inches (333 mm)

Front Track: 13.10 inches (333 mm)

Rear Track: 13.10 inches (333 mm)


Height: 8.34 inches (212 mm)

Wheelbase: 11.62 inches (295 mm)

Center Ground Clearance: 2.44 inches (62 mm)

Driveline: Shaft-driven 4WD

Differential Type: Hardened steel bevel, sealed, limited slip

Gear Ratio (Internal): 15.36:1

Gear Pitch: 32 pitch

Steering Servo: 2057 metal gear waterproof

Radio System: TQi™ Sport 2.4 GHz 2-channel radio with TSM®

Battery Compartment Specs: 162 mm X 50 mm X 26 mm


MOTOR SPECS

Name: Velineon V3200 (patent pending)

Motor Type: Sensorless brushless

Weight: 7.48 ounces (212 g)

Length: 3.15 inches (80 mm)

Diameter: 1.53 inches (39 mm)

Shaft Size: 5 mm

Connector Type: 3.5 mm Bullet


ESC SPECS

Name: VX3 Electronic Speed Control
ESC Type: Brushless
Voltage Range: 2-cell or 3-cell LiPo (NiMH not supported)
Case Size: 2.40″ (61 mm) x 2.09″ (53 mm) x 1.69″ (43 mm)
Weight: 4.20 ounces (119 g)
BEC Voltage: 6.0 volts
Motor Connectors: 3.5 mm Bullet
Battery Connectors: Traxxas High-Current Connector

What’s In The Box:
Stampede 4X4 Brushless with VX3 ESC and V3200 motor
TQi Sport 2.4 GHz radio system
High quality maintenance tools
