XL-5 (WATERPROOF) ESC SPECIFICATIONS Input voltage: ­ 7.2 - 8.4 volt (NiMH), 7.4 volt (LiPo) Case Size: ­ 31 mm x 55 mm x 15.5 mm Weight: ­ 2.44 ounces Motor Limit: ­ 15-turns** (540 Size) 12-turns** (550 Size) On Resistance Forward: ­ 0.007 ohms On Resistance Reverse: ­ 0.014 ohms BEC Voltage: ­ 6.0 volts BEC Current: ­ 1 amp Power Wire: ­ 14 gauge / 5 inches Input Harness Wire: ­ 26 gauge / 9 inches PWM Frequency: ­ 1600 Hz Low Voltage Detection (LVD): ­ 2-stage indicators, switchable (on or off) Thermal Protection: ­ Thermal shutdown Profile selection: ­ Sport Mode: 100% FWD, 100% brakes, 100% REV Race Mode: 100% FWD, 100% brakes, no REV Training Mode:* 50% FWD, 100% brakes, 50% REV Single-button setup: ­ Traxxas EZ-Set® SLASH (58234-8) SPECS Length ­ 22.8 inches (578 mm) Front Track ­ 11.65 inches (296 mm) Rear Track ­ 11.65 inches (296 mm) Weight ­ 76.2 ounces (2.16 kg) Height (overall) ­ 8.43 inches (214 mm) Wheelbase ­ 13.2 inches (335 mm) Front Shock Length ­ Long Rear Shock Length ­ XX-long Front Tires ­ Traxxas SCT 2.2″ Rear Tires ­ Traxxas SCT 2.2″ Front Wheels ­ 2.2″ satin-finish Rear Wheels ­ 2.2″ satin-finish Speed Control ­ Waterproof XL-5 Motor (electric) ­ Titan® 12T 550 (12-turn) Gear Ratio (internal) ­ 2.72 (final drive: 12.58) Differential Type ­ Steel composite planetary Gear Pitch ­ 48 Pitch Transmission ­ Metal gear Magnum 272™ Steering ­ Bellcrank Chassis Type ­ Modified tub Chassis Material ­ Composite Nylon Center Ground Clearance ­ 3.5 inches (89 mm) Top Speed ­ 30+ mph Skill Level ­ 1 Radio System ­ TQ™ 2.4 GHz (2-channel) Included Charger ­ Traxxas 4-amp USB-C fast charger Included Batteries ­ Traxxas 7-cell NiMH battery with iD® Required Batteries ­ 4 "AA" (transmitter) Extreme Heavy Duty Upgrade Components Strengthened C-hubs, axle carriers, and steering blocks Waterproof XL-5™ Electronic Speed Control Innovative watersealed design Three programmable drive profiles Sport Mode - Forward / Brake / Reverse Race Mode - Forward / Brake Training Mode™ - 50% Forward / Brake / 50% Reverse Traxxas EZ-Set® one-button setup Thermal shutdown protection Built-in two-stage low-voltage detection for LiPo batteries NiMH battery packs: 6-7 cells (7.2 to 8.4 volts) LiPo battery packs: 2 cells (7.4 volts) Titan 12-Turn Brushled 550 Motor Internal cooling fan Low-maintenance design TQ™ 2.4 GHz Transmitter Full-size 2-channel transmitter All-day comfort with precise long-range control Watertight receiver box keeps the receiver dry Steering 2075 Digital high-torque waterproof steering servo 125 oz-in of torque and 0.16-second speed Heavy duty servo saver Suspension Adjustable steel turnbuckles and captured rod ends White powder-coated springs Oil-filled Ultra Shocks™ 13.2″ Tough Fiber-Composite Chassis Over 3.5 inches of ground clearance Scale front and rear tube-style bumpers Nerf bars absorb side impacts Easy access battery compartment Transmission and Driveline Heavy-Duty Magnum 272™ metal-gear transmission Torque-Control™ slipper clutch Planetary gear differential with steel ring gear External gear cover with easy clutch access Wheels and Tires Dual-profile black & chrome Split-Spoke SCT wheels Pre-glued BFGoodrich® Mud Terrain T/A® tires Hex hardware with Rust-Resistant Black Oxide Coating Clipless body Body reinforcements to prevent pull-through damage Holds tight for intense action Quick and easy removal
